| Picture/Display | |
| LCD panel type | TFT-LCD |
| Backlight type | W-LED system |
| Panel Size | 18.5 inch / 47 cm |
| Effective viewing area | 409.8 (H) x 230.4 (V) |
| Aspect ratio | 16:09 |
| Optimum resolution | 1366 x 768 @ 60 Hz |
| Response time (typical) | 5 ms |
| Brightness | 200 cd/m≤ |
| Contrast ratio (typical) | 700:01:00 |
| Pixel pitch | 0.30x 0.30 mm |
| Viewing angle | 90∫ (H) / 65∫ (V) |
@ C/R > 10 |
|
| Display colors | 16.7 M |
| Scanning Frequency | 30 -83 kHz (H) / 56 -76 Hz (V) |
| sRGB | Yes |
| Connectivity | |
| Signal Input | VGA (Analog ) |
HDMI (digital, HDCP) |
|
| Sync Input | Separate Sync |
Sync on Green |
|
| Convenience | |
| User convenience | Power On/Off |
| OSD Languages | Brazil Portuguese |
Czech |
|
Dutch |
|
English |
|
Finnish |
|
French |
|
German |
|
Greek |
|
Hungarian |
|
Italian |
|
Japanese |
|
Korean |
|
Polish |
|
Portuguese |
|
Russian |
|
Simplified Chinese |
|
Spanish |
|
Swedish |
|
Traditional Chinese |
|
Turkish |
|
Ukranian |
|
| Other convenience | Kensington lock |
VESA mount (100x100mm) |
|
| Plug & Play Compatibility | DDC/CI |
Mac OS X |
|
sRGB |
|
Windows 7 |
|
Windows 8 |
|
| Stand | |
| Tilt | -3/10 degree |
| Power | |
| On mode | 15.24 W (typ.), 17.65 W (max.) |
| Standby mode | 0.5 W (typ.) |
| Off mode | 0.5 W (typ.) |
| Power LED indicator | Operation - White |
Standby mode- White (blinking) |
|
| Power supply | Built-in |
100-240VAC, 50-60Hz |
|
| Dimensions | |
| Product with stand (mm) | 437 x 338 x 170 mm |
| Product without stand (mm) | 437 x 273 x 48 mm |
| Packaging in mm (WxHxD) | 481 x 350 x 103 mm |
| Weight | |
| Product with stand (kg) | 2.15 kg |
| Product without stand (kg) | 1.94 kg |
| Product with packaging (kg) | 3.00 kg |
| Operating conditions | |
| Temperature range (operation) | 0∞C to 40∞C ∞C |
| Temperature range (storage) | -20∞C to 60∞C ∞C |
| Relative humidity | 20%-80 % |
| Altitude | Operation: 12,000ft (3,658m), Non-operation: 40,000ft (12,192m) |
| MTBF | 30,000 hour(s) |
| Sustainability | |
| Environmental and energy | RoHS |
Mercury Free |
|
| Recyclable packaging material | 100 % |
| Compliance and standards | |
| Regulatory Approvals | CE Mark |
FCC Class B |
|
EAC |
|
SEMKO |
|
BSMI |
|
cETLus |
|
TUV/ISO9241-307 |
|
| Cabinet | |
| Color | Black |
| Finish | Hairline (front bezel) / Texture (rear cover) |
